Ironclad Lite

Ironclad automates contracting processes for the legal, sales, and operational sides of businesses.

Features

Feature Name	Supported	Notes
Capture deletes		All tables except the `WORKFLOW` table and its child tables.
History mode
Custom data		`RECORD`, `WORKFLOW`, and `WORKFLOW_SCHEMA` tables.
Data blocking		Column level
Column hashing
Re-sync		Connection level and table level. A parent table re-sync includes all associated child tables.
API configurable		API configuration
Priority-first sync
Fivetran data models
Private networking
Authorization via API

Supported deployment models

We support the SaaS and Hybrid deployment models for the connector.

You must have an Enterprise or Business Critical plan to use the Hybrid Deployment model.

Setup guide

Follow our step-by-step Ironclad setup guide to connect Ironclad with your destination using Fivetran connectors.

Sync overview

To capture new records, we incrementally sync the following tables and their child tables:

WORKFLOW
WORKFLOW_PARTICIPANT
WORKFLOW_REVIEWER
WORKFLOW_SIGNER

To capture updates and deletes, we re-import the following tables and their child tables:

GROUPS
RECORD
SCHEMA
USERS
WORKFLOW_SCHEMA

Schema information

This schema applies to all Ironclad connectors.

Explore Ironclad schema ERD

Custom data

The Ironclad connector extracts custom data from source tables into separate destination tables.

Source Table	Destination Table
`RECORD`	`RECORD_PROPERTY`
`WORKFLOW`	`WORKFLOW_ATTRIBUTE`
`WORKFLOW_SCHEMA`	`WORKFLOW_SCHEMA_PROPERTY`

We store the custom field name and value (JSON string) in the name and value columns of the destination table. The table also contains a foreign key column to the original table from which we extracted the custom data.

Limitations

We do not support Webhooks events.
