Autodesk BIM 360 & Construction Cloud Lite
Autodesk BIM 360 & Construction Cloud (formerly known as Autodesk BIM 360) is a cloud-based construction management platform.
Features
| Feature Name | Supported | Notes |
|---|---|---|
| Capture deletes | check | ASSET, CATEGORY, CUSTOM_ATTRIBUTE, ERROR_CODE, HUB, ISSUE, ISSUE_ATTRIBUTE, ISSUE_ATTRIBUTE_MAPPING, ISSUE_COMMENT, ISSUE_PROFILE, ISSUE_ROOT_CAUSE_CATEGORY, ISSUE_TYPE, PROJECT, SHEET, SHEET_UPLOAD, STATUS_STEP, and VERSION_SET tables |
| History mode | ||
| Custom data | ||
| Data blocking | check | |
| Column hashing | check | |
| Re-sync | check | |
| Row filtering | ||
| API configurable | check | API configuration |
| Priority-first sync | ||
| Fivetran data models | ||
| Private networking | ||
| Authorization via API | check |
Supported deployment models
We support the SaaS and Hybrid deployment models for the connector.
You must have an Enterprise or Business Critical plan to use the Hybrid Deployment model.
Setup guide
Follow our step-by-step Autodesk BIM 360 & Construction Cloud setup guide to connect Autodesk BIM 360 & Construction Cloud with your destination using Fivetran connectors.
Sync overview
To capture new records, we incrementally sync the following tables:
ASSETCATEGORYCUSTOM_ATTRIBUTEFORMFORM_TEMPLATEISSUEISSUE_ATTRIBUTEISSUE_ATTRIBUTE_MAPPINGISSUE_ROOT_CAUSE_CATEGORYISSUE_TYPERFISTATUS_STEP
To capture updates and deletes, we re-import the remaining tables and their child tables during every sync.
Schema information
This schema applies to all Autodesk BIM 360 & Construction Cloud connections.
Explore Autodesk BIM 360 & Construction Cloud schema ERD
